Zhongke Xinhui (Hubei) Computer Co., Ltd

Using nationally produced processors and related components,
Fully autonomous and controllable native X96 architecture, excellent performance, convenient platform porting, and good compatibility with upper layer applications
Widely used in fields such as AI networks, cloud computing, data storage, gaming, etc
Integrated intelligent management chip, providing an open management platform and supporting multiple management protocols
Support various management functions such as remote monitoring of key component status and abnormal alarms

Product specifications

Model	XR5280 H2
Chassis Specifications	2U (Max Depth: 788mm)
Processor	Supports 1-2 × Haiguang 7200/7300/5200/5300 series CPUs 32-core 64-thread architecture
Memory	32 × DDR4 DIMM slots
Storage Controller	12Gb/s SAS RAID controller Supports RAID 0/1/5/6/50/60 Cache supercapacitor protection with RAID state migration and configuration retention
Drives	Front: 12 × 3.5" or 25 × 2.5" drives Rear: 6 × 2.5" drives Internal: 2 × M.2 SSD slots (onboard)
PCIe Slots	Up to 10 × PCIe standard slots
GPU	Supports 2 × full-height/full-length dual-width GPUs or 4 × full-height/full-length single-width GPUs
Network Card	Dual-port Gigabit standard Supports Gigabit/10GbE multi-port expansion
Power Supply	550W/800W/1300W hot-swappable PSU options
Warranty	3-year nationwide on-site limited warranty with installation service
